用处与简绍/Brief Introduction：

终端服务器按照特异三通管罐装仪器阀，会比较适合水剂和膏霜类护肤品的罐装仪器，有点对高用户消费黏性原料（如浓酱、辣子酱、番茄酱、种衣剂、微乳剂、漂浮剂等）的体验会比较突出，且定位精更高。终端服务器按照PLC可程序语言调控，和65英寸触感屏人机对战控制界面仪器，实施半自功化进瓶，半自功化罐装仪器，半自功化出瓶，电热器，气动弹簧元核心部件均按照新国际该品牌，保证了突出的高质量和经久增强的性能方面。本仪器形式很简单，控制便于，是我国好的专门针对高用户消费黏性原料的罐装仪器仪器。终端服务器具备了以防漏滴与拔丝工艺的罐装仪器闷头，保证罐装仪器完成后无漏滴，无拔丝工艺。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

作用/Characteristic：

◆操控整体——用到三菱PLCPLC操控整体，分装极量随机性稍微调整。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆操控游戏接口——64英寸彩屏手触式操控游戏接口，直观性 简短、安全性高是真的吗Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆模块键改进方案——下料机有防滴漏问题保护装置，可会按照材料因素有下潜分装模块键。（此模块键行应用）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电热器部件——均进行国家知名度公司，确定系统的安全管理靠得住、精确性性好；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆机核心安全装置——机械设备核心安全装置均主要按照质量上乘304不锈铝合金作,烦请需求接受货品可主要按照316L另记账用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆记数验测——时实记数，对运转产能形象造成。Counting test, real-time, intuitive reflect the yield of work.◆灌装生产线验测——无瓶不灌、瓶数跟不上不灌Bottle filling test - no bottle no filling, not enough◆运营事情——该机不符合GMP规定，可不累拆换、除污运营。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆互换年纪——撤换装罐年纪时，只需要比较简单修整，快些搞懂。Changing specifications - change the filling specifications, simply adjust, easy fix.◆的绿色环境保护性能——性能了的绿色环境保护结构，使机子的进行大环境更多洁面安全卫生。（此的绿色环境保护性能能否配搭）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

技术工艺指标/technical parameters：

灌装生产线头数The number of filling head	8头（可选装4、6、8、10、18个灌装生产线头）8 head (opౠtional 4, 6, 8, 10, 12 filling head)
适用性瓶径 Applicable bottles Drive	Ф33-Ф100 mm
计量校准可靠性强，精密度measure precision	±1%
罐装功率Canned capacity	150-1000ml
工作本事Production Capacity	2400-4000瓶/H2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
