的主要用途与简单介绍/Brief Introduction：

该机组为10-20ml内服液气体分装产出线中的重点主机器。是由洗瓶、干燥机一起机和分装密封一起机所根据，能全自动是内服液瓶的洗瓶、干燥机、分装和密封等运动，是内服液产出制造商更梦想的配合主机器，是适合GMP必须。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

优势特点/Characteristic：

◆装量小于，杜决渗漏。罐装gps精性好。High filling accuracy.◆定频无及调节，产生高速度慢可以调整，可供选择择各不相同的产生高速度慢。Frequency control, production speed is adjustable, you can choose a different production rate.◆全部电器开关元器件均使用进出口著名品店牌。All electrical components are imported famous brands.◆一键提示 运算用途。Automatically countting function.◆把控适用日三凌PLC，抗扰乱，做工作稳固。Controlled by Mitsubishi PLC◆比较稳定性比较稳定，保障检修非常方便。Stable performance, easy maintenance.◆服务器看起来应用SUS304不锈不銹钢钢板网作、与原辅材料接觸一些应用316L不銹钢。服务器全部按GMP符合要求设定。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

技术水平参数表/technical parameters：

实用型号规格/Bottle size	10-20ml
种植本事/Capacity	60-90瓶/1分钟/60-90bottles/min
烘干机湿度/Dryer tempreture	100-300°
回收利用流水量/Water wastage	0.5m3/h
净化处理水耗量/Purifying water consumption	0.3m3/h
装量控制精度/Filling precision	≤1%
电原/Voltage	380V/50Hz
耗油率/Power	33KW
生产制造线总长/Dimension	3500×1500×1600mm
