应用场景与概况/Brief Introduction：

该线由渐渐式挤出机螺杆洗瓶吹干箱集成机、服用液包装轧盖机二台手机单机联机包含，划分刷洗、粗糙过滤除菌处理和包装封膜这三个操作区，长线可一体化生產，也可手机单机联机适用。可完毕淋水、超声心动图波刷洗、冲水、冲气、吹干箱过滤除菌处理、冷凝、包装、理盖、戴盖、轧盖等工作。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

性能/Characteristic：

选取多普勒彩超波清洁及气水循环擦拭、远红外高温高压灭菌处理、双头装灌与封口处等能力。整线对接自动化把控。操作步骤简约更方便，完成了有限公司分立式化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

技艺因素/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
用于尺寸 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(这当中正常值工做36Kw)(including normal working 36🎀 kw)
机气净重量machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
